Ivy

Maker	Divergent Waves
Type	Switched capacitor phaser
Mounting	Mixed
Width	4 HP
License	Proprietary (CC BY-NC-SA 4.0, noncommercial so not an open licence)
Difficulty	🌶️ Large through-hole

The folder is named leaky-bucket. The core circuit comes from a 1975 Elektor article, with a 555 added to control the switching rate. Still to be tested.
