LPG

Maker	Divergent Waves
Type	Vactrol low pass gate with cutoff CV plus deep and drive controls
Mounting	Through-hole
Width	4 HP
License	Proprietary (CC BY-NC-SA 4.0, noncommercial so not an open licence)
Difficulty	🌡️ Medium through-hole

Clone of Based on the LPG and CV Tools design from modularsynth.wordpress.com. Draws a surprising 50 mA on plus 12V. Input level is cut slightly, so boost afterwards if needed.
