Yarns

Maker	TOIL Modular
Type	MIDI to CV interface
Mounting	SMD
Width	—
License	Proprietary (No licence published on this repo)
Difficulty	🌋 Fine-pitch SMD

Clone of Mutable Instruments Yarns, redesigned around an STM32 Blue Pill board. Firmware and schematic differ from the original because of Blue Pill limitations.

Documentation

• Assembly instructions
• Bill of materials (BOM)
• Schematic
• Fabrication files (PCBA-ready)

Links

• Source / files on GitHub
• Maker page
