BYOM Envelope

Maker	Clacktronics
Type	Simple attack and release envelope generator
Mounting	Through-hole
Width	6 HP
License	Proprietary (No licence published)
Difficulty	🧊 Low-count through-hole

Through hole AR generator with a gate LED. About twenty parts.
