3320 High Pass Filter

Maker	Guru Gara Synth
Type	CEM3320 or AS3320 high pass filter
Mounting	Through-hole
Width	8 HP
License	Proprietary (No licence published)
Difficulty	🌡️ Medium through-hole

High pass sibling of the 3320 low pass, with a wide resonance range.
