8038 LFO

Maker	Guru Gara Synth
Type	ICL8038 function generator LFO with square, triangle and sine
Mounting	Through-hole
Width	—
License	Proprietary (No licence published)
Difficulty	🌡️ Medium through-hole

Discontinued as a product, but the maker put the full gerber package up as a free download, which is the only Guru Gara design released that way. No BOM or schematic is published with it, and the panel width is not stated.

Documentation

• Assembly instructions
• Fabrication files (PCBA-ready)

Links

• Maker page
• Buy: Guru Gara Synth (free gerber download)
