Maker	Marten Agren
Type	Eight channel modular to line level output conversion module
Mounting	SMD
Width	6 HP
License	Open source (MIT over a hardware-only repo)
Difficulty	🌋 Fine-pitch SMD

Sixteen jacks packed into a narrow board with TSSOP-14 buffers and 0603 passives.
