DIY Eurorack Builds

M4

MIDI processing unit ยท System80

MakerSystem80
TypeMIDI processing unit
MountingSMD
WidthNot listed
LicenseProprietary (CC BY-NC-SA, noncommercial so not an open licence)
Difficulty ๐ŸŒ‹ Fine-pitch SMD

No README, so the function is only described by the repo blurb. Panel SVG and drill centres are committed alongside the gerbers.

Documentation

This is a third-party open-source design, listed here as a build reference. Specs are researched from public sources; check the source repo and store for the current BOM, panel, and revision before ordering parts. Corrections welcome.
