Pulse

Maker	Avalon Harmonics
Type	Heartbeat sensor converted to CV, gates and triggers
Mounting	Through-hole
Width	4 HP
License	Open source (CC BY-SA 4.0 on the design files)
Difficulty	🌡️ Medium through-hole

A fingertip pulse sensor drives the outputs. Finding a stable spot on the finger takes some experimentation.

Documentation

• Bill of materials (BOM)
• Schematic

Links

• Source / files on GitHub
• Maker page
