Ball

Maker	Mountjoy Modular
Type	Bluetooth LE gyroscope remote with a Eurorack base module that outputs three CVs
Mounting	SMD
Width	4 HP
License	Proprietary (No hardware licence published)
Difficulty	🌋 Fine-pitch SMD

A handheld sphere holds an STM32WB35 and an L3GD20 gyroscope on a Li-Po battery. The 4HP base module receives over BLE and converts the three axes into control voltages.
