Vulcan DCO

Maker	Gerbster
Type	Digitally controlled oscillator based on the Roland Juno DCO core
Mounting	Through-hole
Width	—
License	Proprietary (No licence published)
Difficulty	🌶️ Large through-hole

Clone of Roland Juno 106 DCO core. A microcontroller clocks an analog ramp generator, and a DAC compensates the input voltage so amplitude stays flat as frequency rises. Built and working, only the final faceplate is outstanding.
