Clock Divider

Maker	Guru Gara Synth
Type	Clock divider on the 4017 decade counter
Mounting	Through-hole
Width	6 HP
License	Proprietary (No licence published)
Difficulty	🧊 Low-count through-hole

Straight digital divider for polyrhythms and drum patterns.
