ADSR Mega32

Maker	Johansen Engineering
Type	ATMega32A driven ADSR envelope board
Mounting	Mixed
Width	—
License	Proprietary (No licence published on this repo)
Difficulty	🔥 SMD (0805)

The repo mixes three projects: the ADSR board itself, a second revision PT2399 reverb and a Formant style VCO. Note the MIT licence file sits over a hardware project.
