Reverb Module

Maker	Guru Gara Synth
Type	Belton BTDR-2H reverb with a VCA on the wet signal
Mounting	Through-hole
Width	8 HP
License	Proprietary (No licence published)
Difficulty	🌡️ Medium through-hole

Through hole around a Belton brick, with a 3360 based dual VCA on the wet path so the reverb level takes CV. No build document is published for this one.
