Sidechain VCA

Maker	Guru Gara Synth
Type	Dual gain reduction VCA, CV turns the level down
Mounting	Through-hole
Width	12 HP
License	Proprietary (No licence published)
Difficulty	🌡️ Medium through-hole

Works the opposite way round to a normal VCA, so a kick trigger ducks whatever is passing through. Built on the 3360.
