TH 555 VCO

Maker	Jypma
Type	Thomas Henry 555 based VCO
Mounting	Mixed
Width	10 HP
License	Proprietary (No licence published)
Difficulty	🌶️ Large through-hole

Clone of Thomas Henry 555 VCO, from Gerbrand Sterrenburg's board. Through hole apart from the TL074 and LM13700, which were moved to SOIC for availability.
