Abakus

Maker	CATs Eurosynth
Type	14HP counter and gate processing module
Mounting	SMD
Width	14 HP
License	Proprietary (Hardware CC BY-NC-SA 4.0, noncommercial so not an open licence)
Difficulty	🌋 Fine-pitch SMD

Uses 0402 passives across the main board, so hand assembly is demanding.

Documentation

• Bill of materials (BOM)
• Schematic
• Fabrication files (PCBA-ready)

Links

• Source / files on GitHub
• Maker page
