Multiout

Maker	CATs Eurosynth
Type	Seeeduino XIAO multi output module for sequencing, quantizing and envelopes
Mounting	SMD
Width	6 HP
License	Proprietary (Hardware CC BY-NC-SA 4.0, noncommercial so not an open licence)
Difficulty	🌋 Fine-pitch SMD

Clone of HAGIWO SH-101 type sequencer and dual quantizer with envelope generator. Firmware choices cover an SH-101 style sequencer and a dual quantizer with envelope generator. The internal DAC was replaced with a second MCP4725 for 12 bit output on both channels.
