Improved Steiner VCF

Maker	CATs Eurosynth
Type	Steiner Parker style multimode filter with low, high, band and notch responses
Mounting	SMD
Width	8 HP
License	Proprietary (Hardware CC BY-NC-SA 4.0, noncommercial so not an open licence)
Difficulty	🔥 SMD (0805)

Clone of YuSynth Improved Steiner VCF v2. 0805 passives. Adapted to plus and minus 12V from the original design.
