| Maker | EchelonForce |
|---|---|
| Type | Noise source built around the Electric Druid Noise2 chip |
| Mounting | Mixed |
| Width | — |
| License | Proprietary (CC BY-NC-SA 4.0, noncommercial so not an open licence) |
| Difficulty | 🌶️ Large through-hole |
Clone of Electric Druid Noise2. Requires a preprogrammed Noise2 chip from Electric Druid. Passives are 1206 SMD on hand solder pads with through hole DIP sockets for the ICs, and no gerbers are committed.
Documentation
Links
This is a third-party open-source design, listed here as a build reference. Specs are researched from public sources; check the source repo and store for the current BOM, panel, and revision before ordering parts. Corrections welcome.
