Display

Maker	CATs Eurosynth
Type	Arduino OLED oscilloscope and spectrum analyzer with four modes
Mounting	SMD
Width	6 HP
License	Proprietary (Hardware CC BY-NC-SA 4.0, noncommercial so not an open licence)
Difficulty	🔥 SMD (0805)

Clone of HAGIWO Oscilloscope and Spectrum Analyzer. 0603 passives. A panel design by Modulove is also included in the folder.

Documentation

• Bill of materials (BOM)
• Schematic
• Fabrication files (PCBA-ready)

Links

• Source / files on GitHub
• Maker page
