Ringfolder

Maker	CATs Eurosynth
Type	Ring modulator and wavefolder in one panel
Mounting	SMD
Width	6 HP
License	Proprietary (Hardware CC BY-NC-SA 4.0, noncommercial so not an open licence)
Difficulty	🌋 Fine-pitch SMD

Clone of HAGIWO Ring Modulator and Wavefolder. 0402 passives throughout.
